Why do I need Picoscope Automotive Training?

Picoscope Automotive Training is essential to get the most out of your ‘scope’. Without training your oscilloscope will not feature heavily in your diagnostic process, and may end up left in the box holding the office door open. That’s one expensive door stop.

Our Basic Pico Oscilloscope Training course is designed to get you scoping with increased confidence. It is ideal for technicians who are new to ‘scopes’ as well as more experienced users.

When Do I need to use an Oscilloscope?

Automotive Oscilloscopes are not new, but they have evolved just like the technology they are used to measure.

The early ‘scopes were used to analyse ignition systems, and have never stopped being used for this purpose, but using a digital storage oscilloscope (DSO) has become necessary due to the speed of modern electrical signals and control methods.

Digital Multi Meters simply do not have the sample rate to display many common electrical signals, so to measure and evaluate these signals you require an oscilloscope.

Picoscope Help

We have put together a number of videos and basic guides to get you started with your scope as well as more detailed videos for more advanced users.

Click here to request a FREE Basic Oscilloscope Guide

Picoscope Automotive Training Course Content

Our courses are designed to develop your knowledge and skills beyond that of just being able to perform these tests, but how to expand your test routine to enable you to diagnose faults quicker and with more assurance.

We offer two levels of picoscope Automotive Training; Basic and Advanced.

Both courses are a mixture of theory and practical sessions and delegates are encouraged to participate as much as possible.

The Basic Course Covers;

  • Basic Scope Set up
  • Triggers
  • Sample Rate
  • Filters
  • Basic Component Testing

The Advanced Course Covers;

  • Detailed Waveform Analysis
  • Relationship testing
  • Pressure Sensor Waveforms
  • Maths Channels

The pico scope is used as the basis for all our Oscilloscope Training courses.
